USB Logic Analyzer - 24MHz/8-Channel - Elmwood Electronics

Parameter Information: Operating Voltage: 0 - 5.5V Frequency: 24MHz Channels: 8 Sampling Rate: 24M/s Voltage Threshold: 1.5V Place of Application: - Fit for Saleae Pulseview - Fit for Arduino ARM FPGA M100 hot. Note: - This logic analyzer requires a PC with a high-speed USB2.0 interface. Package Include: 1 x Logic Analyzer 1 x USB Cable 1 x Dupont Line Logic analyzer collect specified signals and display them to developers through graphical or statistical methods. There are two very important parameters in the logic analyzer, namely sampling depth and sampling frequency. The strength of this logic analyzer lies in its ability to transmit the collected data to the computer in real-time and high-speed through USB communication, so the sampling depth depends on the memory of our computer, ensuring the procurement of sufficient data. The voltage range is 0V and 5.5V, of which 1.5V is the voltage threshold, below 1.5V is considered low, above 1.5V is considered high. 24M sampling rate, can automatically analyze UART, IIC, SPI and many other standard protocols.
